Modular Systems Unsurpassed in Time Resolution

Becker & Hickl continues to advance techniques of Time-Correlated Single Photon Counting (TCSPC) and Fluorescence Lifetime Imaging Microscopy (FLIM) with its family of high performance, high speed electronic modules.

All modules feature:

  • Complete TCSPC systems on single PCI or PCIe boards
  • Free instrument control software for Windows 10 & 7
  • Oscilloscope Mode
  • Single / multiple decay curve mode (wavelength, time/user def.)
  • Multichannel X-Y-t-Mode
  • Direct interface to most detector types
  • Scan clock trigger input
  • Real-time calculation and fitting of FCS curves
  • Optional stepper motor controller for wavelength or sample scanning
  • Optional detector controller module
  • Optional galvo controller module

Selected module information is available below. See our catalog for additional solutions.

ProductDescriptionFluorescence Lifetime Correlation
Spectroscopy
Scanning MicroscopyOptical
Tomography
SPC-130Low cost TCSPC module for spectroscopy
SPC-130EMTCSPC module with extended memory
SPC-134Four-Channel TCSPC power package
SPC-150High-end performance TCSPC Module for imaging
SPC-150NTCSPC Imaging and FCS Module
SPC-150NXHigh-speed TCSPC Imaging and FCS Module
SPC-154Four-Channel TCSPC imaging power package
SPC-160TCSPC Imaging, Multiscaler Imaging and FCS Module
SPC-160 PCIETCSPC/FLIM Module with PCIe Interface
SPC-830High-End TCSPC Module with large on-board memory
DPC-23016 Channel Photon Correlator

Gated Photon Counters / Multiscalers

ProductDescriptionLuminescence
Detection
Time-Of-Flight
Measurement
LIDAR Application
MSA-3005ns Multiscaler
PMS-400A2 Channel Photon Counter

Low cost TCSPC module

  • Time channel width down to 813 fs
  • Electrical Time Resolution 5 ps RMS ( 8 ps FWHM )
  • 10 MHz saturated count rate
  • Standard fluorescence lifetime recording
  • On-line FCS recording
  • Photon distribution mode / Time-tag mode
  • Sequential-recording modes
  • Also available as SPC-132 dual-module package

TCSPC Module with extended memory

  • Time channel width down to 813 fs
  • Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • 10 MHz saturated count rate
  • Improved on-board memory
  • Standard fluorescence lifetime recording
  • On-line FCS recording
  • Photon distribution mode, Time-tag mode
  • Unlimited fast sequential recording
  • Also available as SPC-132-EM dual-module package

Four-Channel TCSPC power package

  • Time channel width down to 813 fs
  • Electrical Time Resolution 5 ps RMS ( 8 ps FWHM )
  • 40 MHz total saturated count rate
  • Four parallel TCSPC channels
  • Standard fluorescence lifetime recording
  • Diffuse optical tomography
  • Photon distribution mode / Time-tag mode
  • Sequential-recording modes

High-end performance TCSPC Module

  • Time channel width down to 813 fs
  • Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • 10 MHz saturated count rate
  • High-speed interface for laser scanning microscopes
  • FLIM: Fluorescence lifetime imaging
  • PLIM: Phosphorescence lifetime imaging
  • FLITS: Lifetime-Transient Scanning
  • FCS in combination with fluorescence lifetime Photon distribution mode, Time-tag mode
  • Parameter-tag mode
  • Unlimited fast sequential recording
  • Also available as SPC-152 dual-module and SPC-154 Power Module Packages

TCSPC Imaging and FCS Module

  • Time channel width down to 813 fs
  • Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • 10 MHz saturated count rate
  • High-speed interface for laser scanning microscopes
  • FLIM: Fluorescence lifetime imaging
  • PLIM: Phosphorescence lifetime imaging
  • FLITS: Lifetime-Transient Scanning
  • FCS in combination with fluorescence lifetime
  • Photon distribution mode, Time-tag mode
  • Parameter-tag mode
  • Unlimited fast sequential recording
  • Also available as SPC-152 dual-module and SPC-154 Power Module Packages

High-resolution Version of SPC-150N

  • Time channel width down to 407 fs
  • Electrical Time Resolution 1.6 ps RMS ( 3.3 ps FWHM )
  • 10 MHz saturated count rate
  • High-speed interface for laser scanning microscopes
  • FLIM: Fluorescence lifetime imaging
  • PLIM: Phosphorescence lifetime imaging
  • FLITS: Lifetime-Transient Scanning
  • FCS in combination with fluorescence lifetime
  • Photon distribution mode, Time-tag mode
  • Parameter-tag mode
  • Unlimited fast sequential recording
  • Also available as SPC-152 dual-module and SPC-154 Power Module Packages

Dual channel TCSPC Imaging and FCS Package

  • Time channel width down to 813 fs Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • 10 MHz saturated count rate
  • High-speed interface for laser scanning microscopes
  • FLIM: Fluorescence lifetime imaging
  • PLIM: Phosphorescence lifetime imaging
  • FLITS: Lifetime-Transient Scanning
  • FCS in combination with fluorescence lifetime
  • Photon distribution mode, Time-tag mode
  • Parameter-tag mode
  • Unlimited fast sequential recording

Four-Channel TCSPC imaging power package

  • Time channel width down to 813 fs
  • Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • Four parallel TCSPC imaging channels
  • 40 MHz total saturated count rate
  • High-speed interface for laser scanning microscopes
  • FLIM: Fluorescence lifetime imaging
  • PLIM: Phosphorescence lifetime imaging
  • FLITS: Lifetime-Transient Scanning
  • FCS in combination with fluorescence lifetime
  • Photon distribution mode, Time-tag mode
  • Unlimited fast sequential recording

High-end TCSPC module

  • Time channel width down to 813 fs
  • Electrical Time Resolution < 3 ps RMS ( 6.5 ps FWHM )
  • 10 MHz saturated count rate
  • Memory buffer size: 8 million photons
  • High-speed interface for laser scanning microscopes
  • Fluorescence lifetime imaging
  • Phosphorescence lifetime imaging
  • FCS in combination with fluorescence lifetime
  • Photon distribution mode, Time-tag mode
  • Sequential recording modes

16 Channel Photon Correlator

  • 16 LVTTL inputs for SPADs or 4 CFD inputs for PMTs
  • Recording of absolute photon times
  • Multiscaler operation ( single-start, multi-stop )
  • 3-channel TCSPC with 165 ps time channel width
  • Recording of singlet/triplet lifetimes
  • Determination of rotational depolarisation times
  • Photon distribution mode, Time-tag mode

Multiscaler

  • Up to 512 k Points/Curve
  • Time/Point 5 ns to 50 ms
  • Count Rate 100 MHz
  • Hardware Accumulation
  • No Dead Time between Sweeps
  • Applications: Time-of-Flight, LIDAR, Fluorescence  and Phosphorescence, Flash Photolysis

Gated Photon Counter / Multiscaler

  • 2 Detector Channels/Module
  • Parallel Operation of up to 4 Modules
  • Up to 64 k Points/Curve
  • Time/Point 250 ns to 100 000 s
  • Count Rate 800 MHz
  • Gating down to 1 ns
  • Hardware Accumulation
  • Event Mode for Single Molecule Detection
  • Hardware Accumulation
  • Applications: Time-of-Flight, LIDAR, Luminescence, Phosphorescence, Trace Analysis, Flash Photolysis, Raman Scattering
